Love me not song on ssd1306 oled dipslay

1#include <Wire.h>
2#include <Adafruit_GFX.h>
3#include <Adafruit_SSD1306.h>
4#include <Fonts/FreeSans9pt7b.h>
5
6#define SCREEN_WIDTH 128
7#define SCREEN_HEIGHT 64
8#define OLED_RESET    -1
9Adafruit_SSD1306 display(SCREEN_WIDTH, SCREEN_HEIGHT, &Wire, OLED_RESET);
10
11void setup() {
12  Serial.begin(115200);
13  if(!display.begin(SSD1306_SWITCHCAPVCC, 0x3C)) {
14    for(;;);
15  }
16  display.setFont(&FreeSans9pt7b);
17  display.setTextColor(WHITE);
18  display.clearDisplay();
19}
20
21void loop() {
22  // ========================================================
23  // THE FULL SONG TIMELINE
24  // Every single word is here. Tweak the delays to match the audio!
25  // ========================================================
26
27  drawScene(0, "I MISS YOU");        delay(1200);
28  drawScene(1, "COME HERE");         delay(1200);
29  drawScene(2, "AND OH...");         delay(800);
30  drawScene(2, "IT'S HARD");         delay(1000);
31  drawScene(3, "TO SEE YOU");        delay(1200);
32  drawScene(4, "BUT I WISH YOU");    delay(1500);
33  drawScene(5, "WERE RIGHT HERE");   delay(1500);
34  drawScene(0, "OHH IT'S HARD");     delay(1200);
35  drawScene(1, "TO LEAVE YOU");      delay(1500);
36  drawScene(3, "WHEN I GET");        delay(1000);
37  drawScene(6, "EVERYWHERE");        delay(1500);
38  drawScene(7, "ALL THIS TIME");     delay(1500);
39  drawScene(8, "I'M THINKING");      delay(1500);
40  drawScene(9, "I'M STRONG");        delay(1000);
41  drawScene(9, "ENOUGH");            delay(800);
42  drawScene(10, "TO SINK IN");       delay(1500);
43  drawScene(11, "OH I DON'T");       delay(1000);
44  drawScene(11, "NEED YOU");         delay(1000);
45  drawScene(12, "BUT I MISS YOU");   delay(1800);
46  drawScene(1, "COME HERE!");        delay(2000);
47
48  // Quick 2-second reset for fast-paced video looping
49  display.clearDisplay();
50  display.display();
51  delay(2000);
52}
53
54// ========================================================
55// THE MASTER SCENE ENGINE (Two-Color Strict Layout)
56// ========================================================
57
58void drawScene(int type, const char* text) {
59  display.clearDisplay();
60
61  // 1. DYNAMIC TEXT CENTERING (Top Yellow Band: Y=0 to 15)
62  int16_t x1, y1;
63  uint16_t w, h;
64  display.getTextBounds(text, 0, 14, &x1, &y1, &w, &h);
65  display.setCursor((128 - w) / 2, 14); // Perfect center math
66  display.print(text);
67
68  // 2. SOLID STICKER EMOJIS (Bottom Blue Band: Y=20 to 63)
69  int x = 64; int y = 44;
70
71  switch(type) {
72    case 0: // Sad
73      display.fillRoundRect(x-16, y-12, 32, 24, 10, WHITE);
74      display.drawLine(x-8, y-2, x-3, y-2, BLACK); display.drawLine(x+8, y-2, x+3, y-2, BLACK);
75      display.drawLine(x-3, y+4, x+3, y+4, BLACK);
76      display.fillCircle(x-18, y+8, 4, WHITE); display.fillCircle(x+18, y+8, 4, WHITE);
77      break;
78
79    case 1: // Big Eyes Reaching
80      display.fillRoundRect(x-18, y-14, 36, 26, 12, WHITE);
81      display.fillCircle(x-7, y-1, 5, BLACK); display.fillCircle(x+7, y-1, 5, BLACK);
82      display.fillCircle(x-8, y-2, 1, WHITE); display.fillCircle(x+6, y-2, 1, WHITE);
83      display.fillRoundRect(x-28, y, 12, 6, 3, WHITE); display.fillRoundRect(x+16, y, 12, 6, 3, WHITE);
84      break;
85
86    case 2: // Hands on Cheeks / Squint
87      display.fillRoundRect(x-16, y-12, 32, 24, 10, WHITE);
88      display.drawLine(x-10, y-3, x-4, y+1, BLACK); display.drawLine(x-10, y+5, x-4, y+1, BLACK);
89      display.drawLine(x+10, y-3, x+4, y+1, BLACK); display.drawLine(x+10, y+5, x+4, y+1, BLACK);
90      display.fillCircle(x-12, y+6, 5, BLACK); display.fillCircle(x-12, y+6, 3, WHITE);
91      display.fillCircle(x+12, y+6, 5, BLACK); display.fillCircle(x+12, y+6, 3, WHITE);
92      break;
93
94    case 3: // Looking Down
95      display.fillRoundRect(x-16, y-12, 32, 24, 10, WHITE);
96      display.fillCircle(x-6, y+4, 3, BLACK); display.fillCircle(x+6, y+4, 3, BLACK);
97      display.drawLine(x-10, y-6, x-6, y-10, WHITE); display.drawLine(x+10, y-6, x+6, y-10, WHITE);
98      break;
99
100    case 4: // Two Characters Together
101      display.fillRoundRect(x-24, y-10, 24, 20, 8, WHITE);
102      display.fillCircle(x-16, y-2, 2, BLACK); display.fillCircle(x-8, y-2, 2, BLACK);
103      display.fillRoundRect(x+4, y-10, 24, 20, 8, WHITE);
104      display.fillCircle(x+12, y-2, 2, BLACK); display.fillCircle(x+20, y-2, 2, BLACK);
105      break;
106
107    case 5: // Two Characters Cuddling
108      display.fillRoundRect(x-18, y-12, 28, 22, 8, WHITE);
109      display.fillCircle(x-8, y-2, 2, BLACK); display.fillCircle(x, y-2, 2, BLACK);
110      display.fillRoundRect(x+6, y-6, 20, 16, 6, WHITE);
111      display.fillCircle(x+12, y, 2, BLACK); display.fillCircle(x+18, y, 2, BLACK);
112      break;
113
114    case 6: // Happy Everywhere
115      display.fillRoundRect(x-16, y-12, 32, 24, 10, WHITE);
116      display.drawLine(x-8, y-2, x-4, y-2, BLACK); display.drawLine(x+8, y-2, x+4, y-2, BLACK);
117      display.fillTriangle(x-5, y+2, x+5, y+2, x, y+8, BLACK);
118      display.fillRoundRect(x-24, y-10, 8, 8, 4, WHITE); display.fillRoundRect(x+16, y-10, 8, 8, 4, WHITE);
119      break;
120
121    case 7: // Waiting / Looking Up
122      display.fillRoundRect(x-16, y-12, 32, 24, 10, WHITE);
123      display.fillCircle(x-8, y-4, 3, BLACK); display.fillCircle(x+2, y-4, 3, BLACK);
124      display.drawLine(x-4, y+6, x+4, y+6, BLACK);
125      break;
126
127    case 8: // Thinking Bubble
128      display.fillRoundRect(x-24, y-8, 24, 20, 8, WHITE);
129      display.fillCircle(x+6, y-10, 3, WHITE); display.fillCircle(x+14, y-16, 4, WHITE);
130      display.fillRoundRect(x+22, y-24, 34, 16, 5, WHITE);
131      display.setTextColor(BLACK);
132      display.setCursor(x+26, y-12); display.print("???");
133      display.setTextColor(WHITE);
134      break;
135
136    case 9: // Strong Flexing
137      display.fillRoundRect(x-16, y-12, 32, 24, 10, WHITE);
138      display.drawLine(x-6, y-2, x-2, y, BLACK); display.drawLine(x+6, y-2, x+2, y, BLACK);
139      display.fillRoundRect(x-26, y-6, 12, 12, 4, WHITE); display.fillRoundRect(x+14, y-6, 12, 12, 4, WHITE);
140      break;
141
142    case 10: // Sinking in Water
143      display.fillRoundRect(x-16, y-12, 32, 24, 10, WHITE);
144      display.fillRoundRect(x-24, y-2, 8, 14, 4, WHITE); display.fillRoundRect(x+16, y-2, 8, 14, 4, WHITE);
145      display.fillRect(0, y+8, 128, 20, BLACK);
146      display.drawLine(0, y+8, 128, y+8, WHITE);
147      for(int i=0; i<128; i+=10) display.drawLine(i, y+12, i+5, y+12, WHITE);
148      break;
149
150    case 11: // Flash lines
151      display.drawCircle(x, y, 15, WHITE);
152      display.drawLine(x, y-20, x, y-30, WHITE); display.drawLine(x, y+20, x, y+30, WHITE);
153      display.drawLine(x-20, y, x-30, y, WHITE); display.drawLine(x+20, y, x+30, y, WHITE);
154      display.drawLine(x-15, y-15, x-22, y-22, WHITE); display.drawLine(x+15, y+15, x+22, y+22, WHITE);
155      break;
156
157    case 12: // Massive Climax
158      display.fillRoundRect(x-22, y-16, 44, 32, 12, WHITE);
159      display.fillCircle(x-10, y-2, 7, BLACK); display.fillCircle(x+10, y-2, 7, BLACK);
160      display.fillCircle(x-11, y-4, 2, WHITE); display.fillCircle(x+9, y-4, 2, WHITE);
161      display.drawLine(x-3, y+8, x+3, y+8, BLACK);
162      break;
163  }
164
165  display.display();
